Page 64 - ULTRAFLEX Katalog 2021

HIGH PRESSURE FLEXIBLE HOSES

KIT OB: HYDRAULIC HOSE KIT
Two high pressure flexible hoses with pre-crimped brass fittings and bend restrictors on one end. Recommended for use
with all Ultraflex standard helms with 70 Bar (1000 psi) relief valves. With SilverSteer™ and MasterDrive™ systems, use KIT
OB-SVS.
Available lengths: from 3,00 m (9.8 ft) to 9,00 m (29.5 ft) with 0,5 m (1.6 ft) increments.
62

KIT OB LENGTH P. No.
KIT OB-30 3,00 m - 9.8 ft 40852 G
KIT OB-35 3,50 m - 11.5 ft 40853 J
KIT OB-40 4,00 m - 13.2 ft 40752 C
KIT OB-45 4,50 m - 14.8 ft 40753 E
KIT OB-50 5,00 m - 16.4 ft 40754 G
KIT OB-55 5,50 m - 18.0 ft 40755 J
KIT OB-60 6,00 m - 19.7 ft 40749 P
KIT OB-65 6,50 m - 21.3 ft 40648 H
KIT OB-70 7,00 m - 22.9 ft 40796 Z KIT OB
KIT OB-75 7,50 m - 24.6 ft 40854 L
KIT OB-80 8,00 m - 26.3 ft 40855 N
KIT OB-85 8,50 m - 27.8 ft 40856 R
KIT OB-90 9,00 m - 29.5 ft 40857 T

KIT OB/R5: HYDRAULIC HOSE KIT
Two high pressure flexible hoses with pre-crimped brass fittings, R5 bulkhead fittings and bend restrictors on both
OUTBOARD STEERING SYSTEMS
ends. Recommended for use with all Ultraflex standard helms with 70 Bar (1000 psi) relief valves. With SilverSteer™ and
MasterDrive™ systems, use KIT OB-SVS.
Available lengths: from 3,00 m (9.8 ft) to 9,00 m (29.5 ft) with 0,5 m (1.6 ft) increments.

KIT OB/R5 LENGTH P. No.
KIT OB/R5-30 3,00 m - 9.8 ft 40835 G
KIT OB/R5-35 3,50 m - 11.5 ft 40836 J
KIT OB/R5-40 4,00 m - 13.2 ft 40837 L
KIT OB/R5-45 4,50 m - 14.8 ft 40838 N
KIT OB/R5-50 5,00 m - 16.4 ft 40839 R
KIT OB/R5-55 5,50 m - 18.0 ft 40840 Z
KIT OB/R5-60 6,00 m - 19.7 ft 40841 B KIT OB/R5
KIT OB/R5-65 6,50 m - 21.3 ft 40842 D
KIT OB/R5-70 7,00 m - 22.9 ft 40843 F
KIT OB/R5-75 7,50 m - 24.6 ft 40844 H
KIT OB/R5-80 8,00 m - 26.3 ft 40845 K
KIT OB/R5-85 8,50 m - 27.8 ft 40846 M
KIT OB/R5-90 9,00 m - 29.5 ft 40847 P
