Page 40 - ULTRAFLEX Katalog 2021
P. 40
PACKAGED HYDRAULIC STEERING SYSTEMS
OIL
FLEX
HORSEPOWER KIT HELM CYLINDER (1) HOSES (2) litres WHEEL OPTIONAL
TURNS
38 > 300 hp SVS-28 UP28F-SVS UC130-SVS KIT OB-SVS 2 4,6 Steering
wheel
(please refer
to max power Thru hull
applicable) SVS-33 UP33F-SVS UC130-SVS KIT OB-SVS 2 3,9 R8; R9
OIL
POWER UNIT/
HORSEPOWER KIT HELM USER INTERFACE litres WHEEL ORDERED SEPARATELY
TURNS
MD32-F UH32-F UPMD/UCMD 4 4,1
- Outboard cylinder UC130-SVS (1)
> 300 hp MD32-T UH32-T UPMD/UCMD 4 4,1 - Inboard cylinder (1)
(please refer
to max power - X66 tilt mechanism
applicable) MD40-F UH40-F UPMD/UCMD 4 6,5
- Flex hoses: KIT OB-SVS (2)
PACKAGED HYDRAULIC STEERING SYSTEMS
MD40-T UH40-T UPMD/UCMD 4 6,5
NOTE:
1) Please refer to cylinder application chart
2) KIT OB-SVS: see available lengths on appropriate section
SVS-28, SVS 33 MD
