UC128-OBF FRONT                    SPECIFICATIONS                         UC128-OBF/1 -/2 -/3
             MOUNT CYLINDER
                                                  Volume                               120 cc - 7.3 cu. in

                                                Output force                            450 kg - 992 lbs
                                               Internal diameter                         35 mm - 1.37”

                                                   Stroke                               185 mm - 7.28”
                                             3/8” (9.5mm) Fittings                 For high pressure flex hose
                                                                                      DN5 Quick connect
    56                                          Bleed fittings  SPLASHWELL DIMENSION REQUIREMENTS




                                                     Engine No.         A                B                C
                                                        1         560 mm - 22.05”  152 mm - 5.98”   152 mm - 5.98”

                                                        2         1110 mm - 43.70”  152 mm - 5.98”  152 mm - 5.98”


                                                  For twin engine applications minimum engine center distance is 650 mm (26”)

                                  LA1, LA2, LA3 link arm kits for UC128-OBF standard cylinder and LA1P, LA2P link arm kits for
                                  UC128P-OBF port cylinder can also be supplied separately for the first application only, in case
                                  the UC128-OBF cylinder needs to be adapted to the already installed outboard engine (see appli-
                                  cation guide).

                                  “STARBOARD” LINK ARMS:












                                  LA1    40045 A             LA2     40046 C             LA3     40073 F
                                  for UC128-OBF/1            for UC128-OBF/2             for UC128-OBF/3


                                  “PORT” LINK ARMS:










        OUTBOARD STEERING
                                  LA1P   40104 P             LA2P    40105 S
                                  for UC128P-OBF/1           for UC128P-OBF/2



                                          WARNING: LA1, LA2, LA3 and LA1P, LA2P link arm kits are recommended for use on the
                                          first installation only and not as a retrofit. Installation has to be made by qualified technicians
                                          only.
                                          The tightening load to be applied to the screws (included) of the link arm kit is
                                 recommended on the Installation Manual and the mounting instructions supplied with the products.
