Page 184 - ULTRAFLEX Katalog 2021

ORDER GUIDE:

NO. OF
ENGINE ENGINES COMPONENTS P. No. Q.TY

Single control with trim (or no trim) Select control 1
Control Unit 42017F 1
E-Throttle unit Chart A 1
E-Shift unit 42023A 1
Throttle cable Chart B 1
Shift cable Chart C 1
182 Engine Power supply cable (general) 42028L 1 3 1
Chart C
Single
CAN cable
Chart C
Network terminators
Power Unit (optional for second battery) 42026G 1
PwA II-EE Power cable extension (optional for second battery) Chart C 1
Power supply cable (optional for second battery) Chart C 1
Electronic
throttle
Dual control with trim (or no trim) Select control 1
Electric shift Control Unit 42017F 1
E-Throttle unit Tav. A 1
E-Shift unit 42023A 1
Throttle cable Tav. B 2
Shift cable Tav. C 2
Two Power supply cable (general) Tav. C 1
Engines CAN cable Tav. C 3
Network terminators 42028L 1
- ELECTRONIC CONTROL SYSTEM
Power Unit (optional for second battery) 42026G 1
Power cable extension (optional for second battery) Chart C 1
Power supply cable (optional for second battery) Chart C 1

Single control with trim (or no trim) Select control 1
Control Unit 42017F 1
E-Throttle unit Tav. A 1
Mechanical actuator 42027J 1
Throttle cable Tav. B 1
CAN cable Tav. C 3
Single Power supply cable (general) Tav. C 1
Engine Network terminators 42028L 1

Power Unit (optional for second battery) 42026G 1
PwA II-EM
Power cable extension (optional for second battery) Chart C 1
Power supply cable (optional for second battery) Chart C 1
Electronic
throttle Dual control with trim (or no trim) Select control 1
Control Unit 42017F 1
Mechanical shift E-Throttle unit Tav. A 1
Mechanical actuator 42027J 2
Throttle cable Tav. B 2
CAN cable Tav. C 4
Two Power supply cable (general) Tav. C 1
Engines Network terminators 42028L 1
Power Unit 42026G 1
Power extension cable Tav. C 2

Power supply cable (optional for second battery) Chart C 1

For each additional station add:
Single Engine: Single lever control station with trim (or no trim) Select control 1
CAN cable Chart C 1
Two Engines: Dual lever control station with trim (or no trim) Select control 1
CAN cable Chart C 1
