SINGLE LEVER
SIDE MOUNT CONTROLS

Featuring AISI 316 stainless steel lever and bezel,
the B400 has a sleek and modern design which is
ideal for sailboats.

The B400 has an universal control mechanism
that allows for both “push” or “pull” for throttle
and shift, push button warm up, and will accept
33C style cables without any adapters.

Available on request in mechanical version or 187
hybrid version to control the shift by a mechanical
cable and the throttle via 0-5V electric signal.

FEATURES
• 316 stainless steel lever and flange for a
better resistance in the marine environment
• Enables easy and safe shifting by preventing
accidental gear engagement unless engine is
idling
• Can be installed horizontally or vertically, on
the starboard or port side of the boat B400 B401-ETC
• Provided with a brake tension release system
easily adjustable
• Push-in button for throttle operation in
Neutral (ENGINE WARM UP).
• Neutral safety switch X41 - 38130 F included
prevents in-gear starting
• Exceeds EN ISO 11547 standards when X41
safety switch is installed
• B401-ETC (Electronic Throttle Control)
version is available on request. The sensor
has an analog output signal which can be
single or redundant. The output voltage
range is chosen by the customer between 0
and 5V. Power supply 5V +/- 10%, linearity
+/- 1%.
For ETC controls please contact our Technical
Service for custom configuration.
B401-ETC - integrated sensor
• For use with Ultraflex C2, C8, MACHZero
control cables (no kit required)
MODELS
B400 - 42076 Y Fully mechanical version
B401-ETC - 42077 A Hybrid version (machanical shift, electronic throttle)

C
T
80° (60° B401-E
80° (60° B401-ETC) 80° (60° B401-ETC) ) SINGLE LEVER SIDE MOUNT CONTROLS

B400 - B401-ETC
