Outboard Rigging & Accessories
HARNESSES
DBW MAIN HARNESS (16-PIN) MAIN BUS HARNESS (6-PIN) PIGTAIL BUS HARNESS (4-PIN)
Part Number Length Price Part Number Length Price Part Number Length Price
6X6-8258A-50-00 3.7 m (12 ft) 6Y8-82553-41-00 9.1 m (30 ft) 6Y8-82521-51-00 3.6 m (12 ft)
6X6-8258A-60-00 5.2 m (17 ft) 6Y8-82553-31-00 7.6 m (25 ft) 6Y8-82521-41-00 2.7 m (9 ft)
6X6-8258A-00-00 6 m (20 ft) 6Y8-82553-21-00 6.1 m (20 ft) 6Y8-82521-31-00 1.8 m (6 ft)
6X6-8258A-10-00 7 m (23 ft) 6Y8-82553-11-00 4.6 m (15 ft) 6Y8-82521-21-00 0.9 m (3 ft)
6X6-8258A-20-00 8 m (26 ft) 6Y8-82553-50-00 3.0 m (10 ft) 6Y8-82521-11-00 0.6 m (2 ft)
6X6-8258A-30-00 10 m (32 ft) 6Y8-82553-01-00 0.3 m (1 ft) 6Y8-82521-01-00 0.3 m (1 ft)
6X6-8258A-40-00 12 m (38 ft)
SYSTEM POWER SUPPLY WIRE MULTI-HUB SINGLE HUB (INLINE HUB)
Supplies electric power from the key switch to Distributes the digital signal and electric power 6Y8-81920-11-00
the digital network to the gauges and the other hubs. (Multi-Hub
6Y8-83553-01-00 includes ending resistor cap 6Y8-85371-01)
6Y8-81920-01-00
GREY MAIN BUS CONNECTION RED POWER CONNECTION CAP WHITE PIGTAIL CONNECTION
CAP WITH RESISTOR (6-PIN) (2-PIN) CAP (4-PIN)
Ending resistor. Cap for “BUS” on Multi Hub. Cap for “POWER” on Multi Hub. Cap for “DEVICE” on Multi Hub.
6Y8-85371-01-00 6Y8-82582-01-00 6Y8-82582-11-00
