Outboard Rigging & Accessories

REMOTE CONTROL - REMOTE CONTROL ATTACHMENT KITS

The best way to convert your Yamaha outboard throttle and shift
cable from manual to remote operation with the least amount of
fuss.

• Solid & durable corrosion-resistant construction • For use with
remote controls and control cables • Steering hook not included

We strongly recommend that all cable specification and
installation work be carried out by an Authorised Yamaha Dealer,
where further product details and helpful advice are always
available.

ENGINE PART NUMBER PRICE ENGINE PART NUMBER PRICE
9.5A/12A/15A YMM-21201-00-00 F25A/F20A/ FT25B 65W-48501-00-00
4A/5C YMM-21202-00-00 F25D 6BL-48501-00-00
6B/8B 655-48501-02-00 F25G 6FM-48501-00-00
6C/D/8C YMM-21204-00-00
F6A/F6B/F8C/FT8D 6DR-48501-00-00 20C/D/V/30A/G/25D YMM-21207-00-00
9.9D/15D YMM-21205-00-00 20D/25N (‘90--) 6L2-48501-11-00
9.9F/15F YMM-21206-00-00 30D (--’93) 6J8-48501-02-EJ
F15C/F20B 6AH-48501-00-00 25J/30D (‘94--) 6J8-48501-03-4D
F8A/B/F9.9A/B/FT9.9A 6G8-48501-03-00
F9.9C/FT9.9D/F15A 66M-48501-00-00
F9.9F/F9.9J 6DR-48501-00-00 40Q 6R6-48501-00-00
FT9.9G/FT9.9L 6DR-48501-00-00 40X 66T-48501-01-00

CONNECTORS FOR ATTACHMENT KITS
Connector to motor YMM-21220-00-00
Gas connector for YMM-21205-00 YMM-21230-00-00
Gas connector for YMM-21201-00, YMM-21202-00, YMM-21204-00, YMM-21206-00 and YMM-21207-00 YMM-21232-00-00
Shift connector for YMM-21205-00 YMM-21231-00-00
Shift connector for YMM-21201-00, YMM-21202-00, YMM-21204-00, YMM-21206-00 and YMM-21207-00 YMM-21233-00-00

ULTRAFLEX AND TELEFLEX CONTROLS
Model Description Part Number Price
Ultraflex B183 Flush Side Mount YMM-21110-00-00
Ultraflex B85 Flush Side Mount YMM-21111-00-00
Ultraflex B89 Side Mount White (6C-50H) YMM-21100-00-00
Ultraflex B90 Side Mount Black (6C-50H) YMM-21100-10-00
Teleflex Side Mount (6C-50H) YMDRCBOX-00-00

Ultraflex B183 Ultraflex B85 Ultraflex B89 Ultraflex B90 Teleflex Side Mount

26 – Marine accessories
