Outboard Rigging & Accessories

Remote Controls

Yamaha Remote Controls set the standard for operator comfort, convenience and flexibility. Their intuitive ergonomic designs allow
for virtually effortless, one-hand control of throttle and shift functions, and allow for surprisingly easy command of horsepower and
multiple engine installations.

Side mount Top mount Flush mount
NUMBER OF ENGINES Side Mount
Single Twin Triple
REMOTE CONTROL TYPE MODEL MOUNTING POSITION

X
6X6 Top Mount X X Side mount Top mount Flush mount
Top Mount
DIGITAL (DRIVE-BY-WIRE)
(F200G - F350A)
6X7 Flush Mount X

703 Side Mount X
Side mount Top mount Flush mount
Flush Mount
MECHANICAL X X
(F8 -F200F) 704 Top Mount

6X3 Flush Mount X

DIGITAL DRIVE-BY-WIRE (DBW) REMOTE CONTROLS
The operation of throttle and shift is controlled electronically by the Digital Network System, providing you with smoother remote
control - and with no cable friction! Multiple engine remote controls feature automatic engine RPM synchronization.
Thanks to the convenience of our “plug and play” systems, rigging work is now simplicity itself - even 2nd station installation is a breeze.

DBW REMOTE CONTROL BOX FOR SINGLE STATION
Dual Station
Variation Single
# Part Number Engine Mount Price Remarks
Code Station Main
Station 2nd Station
1 6X6-48205-61-00 A Single 1 Single station only
2 6X6-48207-61-00 B Twin Top mount 1 (no extension for dual-station)
3 6X6-48208-61-00 F Triple 1 1
4 6X7-48206-21-00 A Single Flush mount 1 With emergency shut-off cord.
For quad engine installation contact your dealer.
