Fuel and Energy systems

ENGINE BATTERY CABLE
Used to connect Yamaha Outboard Motors to
12V batteries.
Description Part Number
F(T)50 - F(T)60 6C5-82105-01-00
F70 6C5-82105-U1-00
F80/F100/F115/F130A 68V-82105-J1-00
F150 63P-82105-01-00
BATTERY ISOLATOR LEADS F175/F200F/F200G 6DA-82105-01-00
Allows the starter battery to be charged first, V6 3.3L 6P2-82105-02-00
when other battery is being used for onboard V6 4.2L 6CE 6CB-82105-01-00
accessories.
V6 4.2L 6KA 6KA-82105-00-00
Description Part Number
F350A 6AW-82105-01-00
F150A 68F-81949-02-00 XTO 6GR-82105-00-00
F175 to F350 (except V6 69J-81949-02-00
4.2L)
F225F/F250D/F300B V6 6CE-81949-00-00
4.2L
V4 4,2L / 6H 6H2-81949-02-00 WAVERUNNER BATTERY
V4 4,2L / 6K 6K2-81949-02-00 Dry charge WaveRunner battery.
XTO 6GR-81949-01-00 Description Part Number
Battery YUASA YB16CLB EU0821100900
(19AH)

BS BATTERY
Sealed and factory activated battery line by BS.
- No acid handling, Ready & easy to use and Multi-positional fitment
Description Part Number Max Size (mm)
12V-19Ah-260A 907983BB16CL 175x100x175
12V-18A -260A 907983BTX20L 1475x87x155

YAMAHA BATTERY BOXES
Size Max Battery Size Part Number
Small Length 277mm x Width 186mm YMM-BTBX0-00-24
Large Length 327mm x Width 186mm YMM-BTBX0-00-27

BATTERY CHARGERS
Unique battery charging technology: Fully automatic switch mode charger that analyses the state of the battery, charges and automatically switches to
maintenance charging when ready. Includes battery testing, fault detection and float maintenance. Always ensuring a full charge to prolong battery life
time.
Designed for safety: Spark-free, protected from reverse polarity connections and short-circuit proof.
Light and compact: Easy to store and handle.
Yamaha Approved: Tested and approved by Yamaha service engineers to fit and work perfectly with the Yamaha Outboards range.
Quick connection: Combine it with YEC quick connectors - the Built-in Panel Plug, Charger Indicator and Indicator Panel 150 - for reading the charge
condition of your battery and/or for easier access between your Yamaha's battery and the YEC-9 or YEC-50 charger.
Battery Charger Part Number
1 - YEC-9: 6-step charger that can charge the battery of your Yamaha outboard. YME-YEC09-EU-00
2 - YEC-50: 8-step charger that can charge the battery of your Yamaha outboard. YME-YEC50-EU-00
3 - Flushmount charge indicator YME-YECIP-15-00
4 - Charge indicator cable YME-YECPL-05-00

1 2 3 4
