Page 150 - Yamaha Marine Zubehör 2021

Outboard Essentials and Spare parts

KIT60600BAS0 KIT60800BAS0
Part Number Description Qty Part Number Description Qty
69J134400400 ELEMENT ASSY, OIL CLEANER 1 N26134400300 ELEMENT ASSY, OIL CLEANER 1
6DA-12411-01 THERMOSTAT 1 6CE-12411-00 THERMOSTAT 2
94702-00400 PLUG, SPARK (NGK LFR6A-11) 4 94702-00400 PLUG, SPARK (NGK LFR6A-11) 6
90430-14M09 GASKET 1 90430-14M09 GASKET 1
90430-08003 Drain / fill gasket gearbox oil 2 90430-08003 Drain / fill gasket geabox oil 2
6P3WS24A0100 ELEMENT, FILTER 1 6P3WS24A0100 ELEMENT, FILTER 1
6P3-24564-00 GASKET 1 6P3-24564-00 GASKET 1
6CB-24501-01 FILTER, FUEL 1 6CB-24501-01 FILTER, FUEL 1
63P-13915-00 FILTER 1 63P-13915-00 FILTER 1
6CB-14984-00 GASKET, FLOAT CHAMBER 1 6CB-14984-00 GASKET, FLOAT CHAMBER 1
6CB-13016-00 O-RING 1 6CB-13016-00 O-RING 1

KIT60700BAS0 KIT60900BAS0
Part Number Description Qty Part Number Description Qty
69J134400400 ELEMENT ASSY, OIL CLEANER 1 N26134400300 ELEMENT ASSY, OIL CLEANER 1
67F-12411-01 THERMOSTAT 2 6H3-12411-20 THERMOSTAT 1
94702-00400 PLUG, SPARK (NGK LFR6A-11) 6 66M-12411-01 THERMOSTAT 1
90430-14M09 GASKET 1 6GR-12411-00 THERMOSTAT 2
90430-08003 Drain / fill gasket geabox oil 2 94702-00442 PLUG, SPARK (NGK ILMAR7E9) 8
6P3WS24A0100 ELEMENT, FILTER 1 93210-34633 O-RING 1
6P3-24564-00 GASKET 1 6GR-13411-00 STRAINER, OIL 1
6CB-24501-01 FILTER, FUEL 1 932100981100 O-RING 2
63P-13915-00 FILTER 1 6P3WS24A0100 ELEMENT, FILTER 1
6CB-14984-00 GASKET, FLOAT CHAMBER 1 6P3-24564-00 GASKET 1
6CB-13016-00 O-RING 1

ANODE KIT A
Part Number Description
KIT60000ANA0 ANA KIT F30B-F40F-F40H-F50H-F60F
67F-45371-00 Tab Trim for F40G-F70A
KIT60300ANA0 ANA KIT F80D-F100F-F115B-F130A
KIT60500ANA0 ANA KIT F150D-F150F
KIT60600ANA0 ANA KIT F150G-F175A&C-F200F&G
KIT60700ANA0 ANA KIT F200C-F225B-F225F-F250D-F300B
KIT60900ANA0 ANA KIT F425A-XF425N

KIT60000ANA0 KIT60600ANA0
Part Number Description Qty Part Number Description Qty
67C-45371-00 TAB-TRIM 1 6J9-45371-01 TAB-TRIM 1
67C-45251-00 ANODE 1 6AW-45251-00 ANODE 1

67F-45371-00 KIT60700ANA0
Part Number Description Qty Part Number Description Qty
67F-45371-00 Tab Trim for F40G-F70A 1 6CE-45373-00 ANODE 1
6G5-45251-02 ANODE 1
KIT60300ANA0
Part Number Description Qty KIT60900ANA0
6E5-45371-01 TAB-TRIM 1 Part Number Description Qty
6H1-45251-03 ANODE 1 6AW-45373-00 ANODE 1
6AW-45251-00 ANODE 1
KIT60500ANA0
Part Number Description Qty
6J9-45371-01 TAB-TRIM 1
6G5-45251-02 Anodes 1

148 – Dealer Rigging Guide
