Outboard Essentials and Spare parts

Marine Service Kits

Introducing marine service kits! These new kits are tailored for easy servicing of your out board Engine. Blow the kits are shown per
engine family, and seperatly the contest of each kits.

BASIC SERVICE KIT
Part Number Description
KIT60000BAS0 SERV KIT F30B-F40F
KIT60100BAS0 SERV KIT F40H-F50H-F60F
KIT60200BAS0 SERV KIT F40G-F70A
KIT60300BAS0 SERV KIT F80D-F100F
KIT60400BAS0 SERV KIT F115B-F130A
KIT60500BAS0 SERV KIT F150D-F150F
KIT60600BAS0 SERV KIT F150G-F175A&C-F200F&G
KIT60700BAS0 SERV KIT F200C-F225B
KIT60800BAS0 SERV KIT F225F-F250D-F300B
KIT60900BAS0 SERV KIT F425A-XF425N

KIT60000BAS0 KIT60300BAS0
Part Number Description Qty Part Number Description Qty
5GH134406100 ELEMENT ASSY, OIL CLEANER 1 5GH134407100 ELEMENT ASSY, OIL CLEANER 1
62Y-12414-00 Thermostat gasket 1 6FP-12411-00 THERMOSTAT 1
66M124110100 THERMOSTAT 1 94702-00440 PLUG, SPARK (NGK LKR6E 9N) 4
94702-00418 PLUG, SPARK (NGK DPR6EB-9) 3 90430-14M09 GASKET 1
90430-14M09 engine oil gasket 1 90430-08003 Drain / fill gasket geabox oil 2
90430-08003 Drain / fill gasket geabox oil 2 6D8WS24A0000 ELEMENT, FILTER 1
6D8WS24A0000 Fuel filter 1 6D8-24564-00 GASKET 1
6D8-24564-00 O-ring fuel filter 1 6FP-13915-00 FILTER 1
6C5-24251-00 STRAINER 1 1 6FP-14984-00 GASKET, FLOAT CHAMBER 1
6BG-13915-01 FILTER 1 6C5-24251-00 STRAINER 1 1
6BG-14984-00 GASKET, FLOAT CHAMBER 1

KIT60100BAS0 KIT60400BAS0
Part Number Description Qty Part Number Description Qty
5GH134406100 ELEMENT ASSY, OIL CLEANER 1 5GH134407100 ELEMENT ASSY, OIL CLEANER 1
62Y-12414-00 Thermostat gasket 1 6EK-12411-00 THERMOSTAT 1
66M-12411-01 thermostat 1 94702-00437 PLUG, SPARK (NGK LKR6E) 4
94702-00418 SPARK PLUG DPR6EB-9 4 90430-14M09 GASKET 1
90430-14M09 engine oil gasket 1 90430-08003 Drain / fill gasket geabox oil 2
90430-08003 Drain / fill gasket geabox oil 2 6D8WS24A0000 ELEMENT, FILTER 1
6D8WS24A0000 Fuel filter 1 6D8-24564-00 GASKET 1
6D8-24564-00 O-ring fuel filter 1 63P-13915-00 FILTER 1
6C5-24251-00 Strainer 1 1 6CB-14984-00 GASKET, FLOAT CHAMBER 1
6C5-13915-00 filter fuel 1 6CB-13016-00 O-RING 1
6C5-14984-10 GASKET, FLOAT CHAMBER 1

KIT60200BAS0 KIT60500BAS0
Part Number Description Qty Part Number Description Qty
5GH134406100 ELEMENT ASSY, OIL CLEANER 1 69J134400400 ELEMENT ASSY, OIL CLEANER 1
62Y-12414-00 Thermostat gasket 1 63P-12414-00 GASKET, COVER 1
66M124110100 THERMOSTAT 1 67F-12411-01 THERMOSTAT 1
94702-00429 PLUG, SPARK (NGK LKR7E) 4 94702-00391 PLUG, SPARK (NGK LFR5A-11) 4
90430-14M09 engine oil gasket 1 90430-14M09 GASKET 1
90430-08003 Drain / fill gasket geabox oil 2 90430-08003 Drain / fill gasket geabox oil 2
6D8WS24A0000 Fuel filter 1 6P3WS24A0100 ELEMENT, FILTER 1
6D8-24564-00 O-ring fuel filter 1 6P3-24564-00 GASKET 1
6C5-24251-00 STRAINER 1 1 69J-24501-10 FILTER, FUEL 1
6C5-13915-00 filter fuel 1 63P-13915-00 FILTER 1
6C5-14984-10 GASKET, FLOAT CHAMBER 1 63P-14984-00 GASKET, FLOAT CHAMBER 1

Dealer Rigging Guide – 147
