P. 34

ACCESSORIES FOR MECHANICAL STEERING SYSTEMS






            STEERING CABLE SUPPORTS
            S39 - 31916 F
            Clamp block in marine aluminum, stainless steel
            stud and aluminum anodized tube
    32      S40 - 31917 G                                        S39                                  S40
            Corrosion resistant splashwell mount flange,
            aluminum tube
            S55 - 34744 A
            Corrosion resistant 90° rudder support, stainless
            stell flange, aluminum tube


            S61 - 36191 S
            Clamp block, corrosion resistant painted steel
            S62 - 38830 H
            Same design as S61, smaller dimensions

            S39T - 53930 J - Tube only for S39         S55
        ACCESSORIES FOR MECHANICAL STEERING SYSTEMS
            S40T - 53935 O - Tube only for S40
                                                              117 mm                          55 mm
            Steering cable supports with stainless steel
            tube also available:
            S39SS - 41551 X
            S40SS - 41552 Z
            S55SS - 41553 B
            S61SS - 41554 D
            S62SS - 41555 F                                283 mm                           283 mm
            S39TSS - 72971 W Stainless steel tube for
            S39SS                                      S61                             S62
            S40TSS - 72972 Y Stainless steel tube for
            S40SS


            ENGINE CONNECTION KITS
            A50 - 31473 Q
            Connection kit for Yamaha engines
                                  ®
            A73SS - 41255 T
            Stainless steel tiller arm for some
                   ®
            Mercury  engines                            A73SS/A74SS - INOX
            A74SS - 41256 V
            Stainless steel tiller arm for some
            Johnson , Evinrude , BRP engines
                             ®
                                  ®
                   ®
                     WARNING: A73SS and A74SS
                     tiller arms are recommended for
                     mechanical steering systems only
            A75 - 34459 X  Clevis
            STEERING CABLE ADAPTORS                       A50              A75

            K46 – 35679 L
            Adaptor to connect M47 steering cables
            (discontinued) to Morse  D290 and Ultraflex
                                ®
                                                 ®
            FC type steering helms
            K66 –  38432 Q
            Adaptor to connect M66 steering cables
            to Ultraflex  threaded steering helms
                     ®
            (discontinued)

                                                           K46             K66
