3 BOLZEN/SCHÄKEL

SPLINT DIN94 SCHÄKEL GEDREHT KURZ
• Edelstahl AISI 316 / A4 • Edelstahl AISI 316 / A4
D
• geschmiedet
• unverlierbarer Bolzen
L

D5
A
Art.-Nr. Ø x L mm Inhalt je Blister Blister je VE Art.-Nr. D mm A mm L mm D5 mm BL daN VE
40.540.001 2,0 x 20 12 6 08.503.024 4 8 24 3,5 580 1
40.540.002 2,0 x 25 12 6 08.503.025 5 10 30 4,4 910 1
40.540.003 2,0 x 32 12 6 08.503.026 6 12 36 5,3 1320 1
40.540.004 2,0 x 40 10 6 08.503.028 8 16 48 7,1 2370 1
40.540.010 2,5 x 25 10 6 08.503.030 10 20 60 8,9 3730 1
40.540.016 3,2 x 25 8 6
40.540.017 3,2 x 32 6 6 SCHÄKEL GEDREHT LANG -
40.540.018 3,2 x 40 6 6 AUGBOLZEN
40.540.025 4,0 x 20 4 6
• Edelstahl AISI 316 / A4
40.540.026 4,0 x 25 4 6
• geschmiedet
40.540.027 4,0 x 32 4 6
40.540.028 4,0 x 40 3 6
40.540.029 4,0 x 50 3 6
40.540.035 5,0 x 25 2 6
40.540.036 5,0 x 32 2 6
40.540.037 5,0 x 40 2 6
Art.-Nr. A mm C mm L2 mm B mm BL daN VE
40.540.038 5,0 x 50 2 6
08.503.005 5 5 30 10 1000 10
08.503.006 6 6 36 12 1500 10
Art.-Nr. Ø x L mm Verpackt per
08.503.008 8 8 48 16 2500 10
87.540.001 2.0 x 20 100
87.540.002 2,0 x 25 100
SCHÄKEL FORM D
87.540.003 2,0 x 32 100
87.540.004 2,0 x 40 100
87.540.010 2,5 x 25 100
87.540.016 3,2 x 25 100 • Edelstahl AISI 316 / A4
87.540.017 3,2 x 32 100 • flaches Modell
87.540.018 3,2 x 40 100 • profilierter Bügel
87.540.025 4,0 x 20 100 • Patentbolzen
87.540.026 4,0 x 25 100
87.540.027 4,0 x 32 100
87.540.028 4,0 x 40 100 Art.-Nr. D mm A mm L min mm BL daN VE
87.540.029 4,0 x 50 100 08.531.040 4,0 9,0 20,0 460 10
87.540.035 5,0 x 25 100 08.531.050 5,0 10,5 21,0 730 10
87.540.036 5,0 x 32 100 08.531.060 6,0 13,5 28,0 1060 10
87.540.037 5,0 x 40 100
87.540.038 5,0 x 50 100 SCHLÜSSELSCHÄKEL

• Edelstahl AISI 304 / A2
• profilierter Bügel

Art.-Nr. C mm B mm L2 mm VE
08.536.050 5 13 26 10
08.536.051 5 14 36 10
08.536.061 6 14 40 10
08.536.080 8 20 41 10
