Page 109 - Lankhorst Katalog 2021/2022

BOLZEN 3

STECKBOLZEN
• Edelstahl AISI 316 / A4

Art.-Nr. D L L1 D1 D2 Inhalt je Art.-Nr. D L L1 D1 D2 Inhalt je
mm mm mm mm mm Blister mm mm mm mm mm Blister
09.900.210 4,75 10,0 7,0 8,0 2,0 2 09.900.232 8,00 32,0 28,0 12,0 3,0 1
09.900.211 5,00 15,0 11,0 8,0 2,5 2 09.900.240 9,50 19,0 15,0 14,0 4,0 1
09.900.212 5,00 18,0 14,0 8,0 2,5 2 09.900.241 9,50 22,0 18,0 14,0 4,0 1
09.900.213 5,00 21,0 17,0 8,0 2,5 2 09.900.242 9,50 26,0 22,0 13,0 3,0 1
09.900.221 6,00 20,0 16,0 10,0 2,5 2 09.900.250 11,00 25,4 21,4 14,0 4,0 1
09.900.223 6,00 25,0 21,0 10,0 2,5 2 09.900.251 11,00 30,0 25,0 16,0 3,0 1
09.900.230 8,00 21,0 17,0 12,0 3,0 1 09.900.260 12,00 25,4 20,4 16,0 3,0 1
09.900.231 8,00 24,0 20,0 12,0 3,0 1 09.900.261 12,00 30,0 26,0 16,0 3,0 1

STECKBOLZEN MIT RINGSPLINTE
KUGELSICHERUNG
• Edelstahl AISI 316 / A4
• Edelstahl AISI 316 / A4 D 1

L1 L

D
Art.-Nr. D mm L mm L1 mm D1 mm Art.-Nr. Abm. mm Inhalt je Blister Blister je VE
09.911.320 5 25 17 25 09.911.211 1,00 x 11 10 6
09.911.321 6 25 17 25 09.911.212 1,20 x 15 10 6
09.911.322 8 25 17 25 09.911.213 1,50 x 20 6 6
09.911.214 2,00 x 25 4 6
STECKFEDER Art.-Nr. Abm. mm Verpackt per
87.911.211 1,00 x 11 100
• Edelstahl AISI 316 / A4 W
87.911.212 1,20 x 15 100
87.911.213 1,50 x 20 100
87.911.214 2,00 x 25 100

L

D

Art.-Nr. D mm L mm W mm
09.911.420 2,0 48 10
09.911.421 2,5 54 11
09.911.422 3,0 70 16
09.911.423 4,0 78 19
09.911.424 5,0 100 26

T | 05971 / 97 07-0 RIGG 107
