Rigging Order Guide
RIGGING KITS - FOR DBW REMOTE CONTROL
6YC SINGLE DBW RIGGING KIT (WITHOUT SWITCH A
PANEL) B
6Y8-762G-21-00
Parts Number Description Qty No.
6YC-83710-03-00 6YC MULTI FUNCTION COLOUR DISPLAY 1 A
6Y8-81920-01-00 MULTI-HUB ASSY 1 B
6Y8-82582-11-00 TERMINAL CAP (4 PIN/DEVICE) 1 C E
6Y8-82521-11-00 PIGTAIL BUS HARNESS 4 PIN (0.6 M / 2 FT) 1 D
6Y8-82521-31-00 PIGTAIL BUS HARNESS 4 PIN (1.8 M / 6 FT) 1 E
6Y8-8356N-01-00 6Y8 GPS/FUEL WIRE (NMEA 0183) 1 F C
6Y8-83553-01-00 SYSTEM POWER SUPPLY WIRE (2.4 M / 8 FT) 1 G D
6X6-8258A-30-00 DBW MAIN HARNESS 16 PIN (10 M / 32 FT) 1 H H
6YC-2819U-70-00 OWNER'S MANUAL 1 -
6YC-2819U-80-00 OWNER'S MANUAL 1 -
* DBW remote control box and switch panels are required separately. F G
6YC TWIN DBW RIGGING KIT A B
6Y8-762G0-11-00
Parts Number Description Qty No.
6YC-83710-03-00 6YC MULTI FUNCTION COLOUR DISPLAY 1 A
6Y8-81920-01-00 MULTI-HUB ASSY 2 B
6Y8-82553-01-00 MAIN BUS HARNESS 6 PIN (0.3 M / 1 FT) 1 C
6Y8-82582-11-00 TERMINAL CAP (4 PIN/DEVICE) 3 D
6Y8-82582-01-00 TERMINAL CAP (2 PIN/POWER) 1 E
6Y8-82521-11-00 PIGTAIL BUS HARNESS 4 PIN (0.6 M / 2 FT) 1 F C
6Y8-82521-31-00 PIGTAIL BUS HARNESS 4 PIN (1.8 M / 6 FT) 2 G
6Y8-8356N-01-00 6Y8 GPS/FUEL WIRE (NMEA 0183) 1 H F G
6Y8-83553-01-00 SYSTEM POWER SUPPLY WIRE (2.4 M / 8 FT) 1 I D E
6X6-82570-40-00 TWIN ENGINE MAIN SWITCH PANEL 1 J
6X6-82570-60-00 TWIN ENGINE START/STOP PANEL 1 K
6X6-8258A-40-00 DBW MAIN HARNESS 16 PIN (12 M / 38 FT) 2 L H I
6YC-2819U-70-00 OWNER'S MANUAL 1 - J
6YC-2819U-80-00 OWNER'S MANUAL 1 -
* DBW remote control box is required separately.
K L
DBW RIGGING KIT FOR CL7
6YD-762A0-00-00
Parts Number Description Qty No.
6Y8-81920-01-00 MULTI-HUB ASSY 1 A C
6Y8-82553-01-00 MAIN BUS HARNESS 6 PIN (0.3 M / 1 FT) 1 B A
6Y8-82521-31-00 PIGTAIL BUS HARNESS 4 PIN (1.8 M / 6 FT) 1 C
6YD-83553-00-00 CONVERSION HARNESS 1 D
6YD-8356N-00-00 6YD FUEL WIRE 1 E
6Y8-83553-01-00 SYSTEM POWER SUPPLY WIRE (2.4 M / 8 FT) 1 F B
6Y9-83553-00-00 CONVERSION HARNESS (0.3 M / 1 FT) 1 G
6Y8-82582-11-00 TERMINAL CAP (4 PIN) WHITE 2 H H
6Y9-2819K-E0-00 SET-UP MANUAL 1 - G E
6Y9-2819U-72-00 OWNERS MANUAL 1 -
6Y9-2819U-82-00 OWNERS MANUAL 1 -
* DBW remote control box and CL7 display are required separately.
D F
