Outboard Rigging & Accessories

1. Pull 2. Push

703-48261-01-00 703-48261-11-00

703 THROTTLE CONVERSION 704 CONTROL SPACER KITS
Description Part Number Description Part Number
703 Conversion Kit (Pull to Push) 703-48261-01-00 For 704 Premium Single 704-48293-20-00
703 Conversion Kit (Push to Pull) 703-48261-11-00 For 704 Premium Twin 704-48293-30-00

DIGITAL DRIVE-BY-WIRE (DBW) REMOTE CONTROLS
The operation of throttle and shift is controlled electronically by the Digital Network System, providing you with smoother remote
control - and with no cable friction! Multiple engine remote controls feature automatic engine RPM synchronization. Thanks to the
convenience of our “plug and play” systems, rigging work is now simplicity itself - even 2nd station installation is a breeze.

DBW REMOTE CONTROL BOX FOR SINGLE STATION
Variation Single Dual Station
# Part Number Engine Mount Remarks
Code Station Main Station 2nd Station
1 6X6-48205-61-00 A Single 1 Single station only
2 6X6-48207-61-00 B Twin Top mount 1 (no extension for dual-station)
3 6X6-48208-61-00 F Triple 1 1
4 6X7-48206-21-00 A Single Flush mount 1 With emergency shut-off cord.
For quad engine installation contact your dealer.

6X6 DIGITAL DBW REMOTE CONTROL
An exclusive suite of binnacle style drive-by-wire remote control boxes. Available in single, twin or triple engine versions and fully
compatible with Yamaha's Digital Network Systems.

1 - 6X6 SINGLE ENGINE TOP MOUNT 2 - 6X6 TWIN ENGINE TOP MOUNT

3 - 6X6 TRIPLE ENGINE TOP MOUNT
6Y8 (Round) / 6YC / CL7
GAUGE
CL7

ENGINE

SWITCH

6X6 CONTROL SPACER KITS
Description Part Number
6X6 Single Control Box Spacer MARSHIM86500
6X6 Twin Control Box Spacer MARSHIM86600
24 – Dealer Rigging Guide
