ANALOG GAUGES
Premium quality analog instruments made to work in perfect harmony with your Yamaha outboard.
Description Remarks
1 Seedometer Kit/Speedometer assy Speed. Trip. Time. Fuel. Battery voltage.
Engine RPM. Trim angle. Oil level. Hour meter. Water separator warning indicator. Warning
2 Tachometer kit/Tachometer assy
lamps. Engine warning indicator. Overheat warning lamp.
3 Water pressure meter kit Fuel consumption. Fuel economy. Fuel contamination.
4 Water temp. meter kit
5 Fuel meter assy
6 Fuel meter assy
7 Voltmeter assy
8 Trim Gauge
9 Digital speedometer assy
10 Digital tachometer assy
11 Digital fuel meter kit Single
12/22 Speedometer assy
13/23 Tachometer assy
14/24 Water pressure meter assy
15/25 Water temp. assy
16/26 Hour meter assy
17/27 Fuel meter assy
18/28 Trim meter assy
19/29 Voltmeter assy

1 3 12/22 14/24

4 15/25

5 16/26
13/23

6 17/27

2

7 18/28

8 19/29

9 10 11
