Outboard Rigging & Accessories
6X7 DBW SINGLE ENGINE FLUSH MOUNT
A compact, flush side-mounted digital drive-by-wire remote control box with an integrated lanyard switch. Key switch panel and main
wire harness supplied separately.
4 - 6X7 SINGLE ENGINE FLUSH MOUNT
6Y8 (Round) / 6YC / CL7
GAUGE
CL7
ENGINE
SWITCH
DBW REMOTE CONTROL BOX FOR DUAL STATIONS
Variation Single Dual Station
# Part Number Engine Mount Remarks
Code Station Main Station 2nd Station
1a 6X6-48205-71-00 C Single 1 1 For main station
1b 6X6-48205-81-00 G 1 For 2nd station
2a 6X6-48207-71-00 D Twin Top mount 1 1 For main station
2b 6X6-48207-81-00 H 1 For 2nd station
3a 6X6-48208-61-00 F Triple 1 1 For main station
3b 6X6-48208-71-00 K 1 For 2nd station
4a 6X7-48206-31-00 C Single Flush mount 1 For main station
4b 6X7-48206-41-00 G Single Flush mount 1 For 2nd station
Dealer Rigging Guide – 25
