DIGITAL DRIVE-BY-WIRE (DBW) REMOTE CONTROLS

The operation of throttle and shift is controlled electronically by the Digital Network System, providing you with smoother remote
control - and with no cable friction! Multiple engine remote controls feature automatic engine RPM synchronization. Thanks to the
convenience of our “plug and play” systems, rigging work is now simplicity itself - even 2nd station installation is a breeze. For more
detailed information please also see the Helm Master EX section

STATION SINGLE LEVER
Press this button for active Press this button to control
station transfer (when multiple outboards with the
applicable). port-side lever only.

CENTER ENGINE
NEUTRAL HOLD Press this button to run only
This button throttles up the center engine(s) for
the engine(s) without slower trolling.
shift engagement.

6X9 DIGITAL DBW REMOTE CONTROL
An exclusive suite of binnacle style drive-by-wire remote control boxes. Available in single, twin, triple or Quad engine versions and
fully compatible with Yamaha's Helm Master EX

1 - 6X9 SINGLE ENGINE TOP MOUNT 2 - 6X9 TWIN/TRIPLE/QUAD ENGINE TOP MOUNT

6X9 DBW SINGLE ENGINE FLUSH MOUNT
A compact, flush side-mounted digital drive-by-wire remote control box with an integrated lanyard switch. Key switch panel and main
wire harness supplied separately.

3 - 6X9 SINGLE ENGINE FLUSH MOUNT
