INTE RA EPS

SYSTEM COMPONENTS
• UIH - Tilt mount electronic helm
• X52 - Adjustable steering wheel tilt mechanism
• UID - Veratron VDO color display
®
• BCM (Body Control Module) - CAN bus network Module
• UIP - Electro-hydraulic power unit
• UC120E - Heavy-duty cylinder with integrated sensor
• UC120P-OBF - Heavy-duty cylinder for twin, triple or quad outboard engines
82 • KIT OB-SVS - Hydraulic hoses with preassembled fittings
• Tie bar - Please refer to INTEGRA EPS tie bars section
• CAN bus cables - CAN bus power cables
• KBD3 - Purging kit: twin spiralled hose with connectors (optional)
• OL460 - 3x hydraulic oil bottles

ELECTRONIC POWER STEERING SYSTEMS
UIH1 - ELECTRONIC HELM part No. 43536 M

• Electronic steering helm tilt mount (X52)
• Easy to install, no oil or hydraulic hoses
• UIH1 first station electronic helm
UIH2 - 43537 P - second station electronic helm
UIH3 - 43538 S - third station electronic helm
• Resistant to harsh marine conditions
• Steering wheel turns can be set by the user.
• Variable steering wheel resistance according to boat speed
• Instant responsiveness
• Redundant architecture with 2 CAN bus channels

UIH1

X52 - TILT MECHANISM part No. 39250 U

• Tilt range of 48° and 5 locking positions.

INTE RA EPS X52
