P. 34
Outboard Rigging & Accessories
STEERING HOOKS
Model Type Part Number
Universal Steering Hook (A50) for engines between 5 and 25hp YMM-21220-00-00
6C/D/8C/9.9D/15D/40Q Ball post type, not for F8B/F9.9A/B/25J 676-48511-02-00
F6A/F8C/FT8D/F9.9C/FT9.9D/F9.9F/FT9.9G/F9.9J/FT9.9LF15A/9.9F/15F Steering guide type 63V-48511-01-00
F8A/B/F9.9A/B/25J/30D (‘87-’96) Ball post type 6G8-48511-10-00
F8A/B/F9.9A/B/25J/30D (‘87-’96) Steering guide type 6G8-48511-20-00
F15C/F20B 6AH-48511-01-00
20C(‘85-’96) 20D/25B/25D/N/30A/G (‘85-’89) Ball post type/Steering guide type 689-48511-02-00
20D/25N (‘90-’00) Ball post type/Steering guide type 6L2-48511-00-00
20D/25N (‘01-) 25J/30D (‘94--) 6J8-48511-01-4D
25J/30DETO (‘99-’01) Steering guide type 6J8-48511-52-00
F20A/F25A/F25D/F25G/FT25B/FT25F/F30A/F30B/F40B/F40F/F50F/F50H/ Steering guide type 65W-48511-01-00
FT50B/FT50G/FT50J/F60A/F60C/F60F/FT60B/FT60D/FT60G/F70A/40X
25B/50G/60F/70B Steering guide type 6H3-48511-52-00
25B/Q/40H/50D/50G/60F/70B/75A/80A/85A/90A/55B (‘95--) Ball post type 688-48511-01-4D
55B (‘92-’94) Steering guide type 688-48511-51-1D
55B (‘95-’98) Steering guide type 688-48511-52-00
55B (‘90-’94) 75A/85A (‘90-’93) Ball post type 688-48511-01-4D
75C/90A Steering guide type 688-48511-12-00
25Q/40H/50D Steering guide type 6H4-48511-51-4D
40V/Y/F40A/F45A/50H/F50A/B/FT50B/C 63D-48511-01-00
F80A/F80B/F100A/F100D Steering guide type 67F-48511-01-00
F115A Steering guide type 68V-48511-01-00
Outboard Maintenance & Accessories
RIGGING HOSE
Keep your cables protected and uncluttered with a Rigging Hose. Yamaha Hoses are tough yet
flexible and are constructed from crush-resistant, UV-protected material to ensure a longer life span.
Hoses are mounted using a chromium-plated copper or plastic bracket and come in black, gray or
metallic blue colours.
2"
Black 25ft/7,62m MAR-RIGHS-BK-25
Gray/Black 25ft/7,62m ABB-RIGHS-GY-25
White/Black 25ft/7,62m MAR-RHS20-WT-25
Metallic blue 25ft/7,62m ABB-RIGHS-BE-25
2,5" XTO
Black 25ft/7,62m MAR-RHS25-BK-25
White/Black 25ft/7,62m MAR-RHS25-WT-25
RIGGING GROMMETS
These handy devices replace rubber engine grommets on bigger engines and provide positive
attachment without the need for clamps. They can be threaded directly onto one end of a rigging
hose with Transom Brackets at the other end.
115-250 (2-stroke) MAR-GROMM-ET-01
F150 MAR-GRMMT-F1-50
F200B/C-F250A/B MAR-GRMMT-LG-4S
TRANSOM PLATES
Yamaha recommend these transom plates for boats with engines from 60hp and up.
F30 - V6 (non SBW) engines aluminium 10mm YMM-09TP0-00-01
V6 SBW and V8 engines aluminium 10mm YMM-09TP0-00-02
32 – Dealer Rigging Guide
