Outboard Rigging & Accessories

6Y9 TWIN RIGGING KIT
6Y9-W0035-18-00
Parts Number Description Qty
6Y9-83710-13-00 MULTI-FUNCTION COLOUR DISPLAY (6Y9) 1
6Y8-81920-01-00 MULTI-HUB ASSY 1
6Y8-82582-11-00 TERMINAL CAP (4 PIN/DEVICE) 2
6Y8-82553-01-00 MAIN BUS HARNESS 6 PIN (0.3 M / 1 FT) 1
6Y8-82521-31-00 PIGTAIL BUS HARNESS 4 PIN (1.8 M / 6 FT) 1
6Y9-83553-40-00 6Y9 DISPLAY CONVERSION HARNESS 1
6Y9-83553-00-00 DBW MAIN BUS WIRE ADAPTOR HARNESS 1
6Y8-83553-01-00 SYSTEM POWER SUPPLY WIRE (2.4 M / 8 FT) 1
6Y9-8356N-01-00 6Y9 GPS WIRE (NMEA 0183) 1
6Y9-8356N-10-00 6Y9 FUEL WIRE 1
6X6-82570-40-00 TWIN ENGINE MAIN SWITCH PANEL 1
6X6-82570-60-00 TWIN ENGINE START/STOP PANEL 1
6X6-8258A-40-00 DBW MAIN HARNESS 16 PIN (12 M / 38 FT) 2
6Y9-2819K-E0-00 SET-UP MANUAL 1
6Y9-2819U-72-00 OWNERS MANUAL 1
Rigging Kits 6Y9-2819U-82-00 OWNERS MANUAL 1
* DBW remote control box is required separately.
What excatly do you need for your boat and engine?

Even though Yamaha’s Digital Network rigging components are sophisticated, powerful and very advanced, they are made to be simple
to understand and to use. We know too, that choosing exactly the right rigging components to fit your boat can still be a hassle ... but
don’t worry! A Yamaha Rigging Kit will make your choice a breeze - and ordering couldn’t be simpler.

RIGGING KITS - FOR DBW REMOTE CONTROL

6Y9 SINGLE RIGGING KIT (WITHOUT SWITCH PANEL)
6Y9-W0035-27-00 6Y9 TRIPLE RIGGING KIT
6Y9-W0035-46-00
Parts Number Description Qty
Parts Number Description Qty
6Y9-83710-13-00 MULTI-FUNCTION COLOUR DISPLAY (6Y9) 1
6Y8-81920-01-00 MULTI-HUB ASSY 1 6Y9-83710-13-00 MULTI-FUNCTION COLOUR DISPLAY (6Y9) 1
6Y8-82582-11-00 TERMINAL CAP (4 PIN/DEVICE) 2 6Y8-81920-01-00 MULTI-HUB ASSY 1
6Y8-82553-01-00 MAIN BUS HARNESS 6 PIN (0.3 M / 1 FT) 1 6Y8-82582-11-00 TERMINAL CAP (4 PIN/DEVICE) 2
6Y8-82521-31-00 PIGTAIL BUS HARNESS 4 PIN (1.8 M / 6 FT) 1 6Y8-82553-01-00 MAIN BUS HARNESS 6 PIN (0.3 M / 1 FT) 1
6Y9-83553-40-00 6Y9 DISPLAY CONVERSION HARNESS 1 6Y8-82521-31-00 PIGTAIL BUS HARNESS 4 PIN (1.8 M / 6 FT) 1
6Y9-83553-00-00 DBW MAIN BUS WIRE ADAPTOR HARNESS 1 6Y9-83553-40-00 6Y9 DISPLAY CONVERSION HARNESS 1
6Y8-83553-01-00 SYSTEM POWER SUPPLY WIRE (2.4 M / 8 FT) 1 6Y9-83553-00-00 DBW MAIN BUS WIRE ADAPTOR HARNESS 1
6Y9-8356N-01-00 6Y9 GPS WIRE (NMEA 0183) 1 6Y8-83553-01-00 SYSTEM POWER SUPPLY WIRE (2.4 M / 8 FT) 1
6Y9-8356N-10-00 6Y9 FUEL WIRE 1 6Y9-8356N-01-00 6Y9 GPS WIRE (NMEA 0183) 1
6X6-8258A-30-00 DBW MAIN HARNESS 16 PIN (10 M / 32 FT) 1 6Y9-8356N-10-00 6Y9 FUEL WIRE 1
6Y9-2819K-E0-00 SET-UP MANUAL 1 6X6-82570-50-00 TRIPLE ENGINE MAIN SWITCH PANEL 1
6Y9-2819U-72-00 OWNERS MANUAL 1 6X6-82570-70-00 TRIPLE ENGINE START/STOP PANEL 1
6Y9-2819U-82-00 OWNERS MANUAL 1 6X6-8258A-40-00 DBW MAIN HARNESS 16 PIN (12 M / 38 FT) 3
* DBW remote control box and switch panels are required separately. 6Y9-2819K-E0-00 SET-UP MANUAL 1
6Y9-2819U-72-00 OWNERS MANUAL 1
6Y9-2819U-82-00 OWNERS MANUAL 1
* DBW remote control box is required separately.
