Page 29 - Yamaha Zubehör Aussenbordmotoren 2017

Outboard Rigging & Accessories

REMOTE CONTROL - REMOTE CONTROL ATTACHMENT KITS REMOTE CONTROL CABLES

Only the very best cable performs smoothly and reliably enough to be a match for the renowned quality of a Yamaha Remote Control.
The best way to convert your Yamaha outboard throttle and shift
cable from manual to remote operation with the least amount of
fuss.
Premium PowerMatched control cable (YPM)
• Solid & durable corrosion-resistant construction • For use with
remote controls and control cables • Steering hook not included

We strongly recommend that all cable specification and
installation work be carried out by an Authorised Yamaha Dealer, Ultraviolet-stabilised
where further product details and helpful advice are always Stainless Steel 16” max Nickel-plated Rotary swaged high-density Long-lay oil- High-density Nylon-covered
available. Rod Wiper seal swivel brass sleeve Swivel seat stainless steel hub polyethylene outer tempered wires polyethylene stranded core
jacket liner wire

Splines reduce contact area with
liner for ultra low friction
ENGINE PART NUMBER PRICE ENGINE PART NUMBER PRICE
9.5A/12A/15A YMM-21201-00-00 F25A/F20A/ FT25B 65W-48501-00-00
4A/5C YMM-21202-00-00 F25D 6BL-48501-00-00
6B/8B 655-48501-02-00 F25G 6FM-48501-00-00 STANDARD CABLE (Y32)
6C/D/8C YMM-21204-00-00 Yamaha offers you a choice of remote control cables that are a perfect match for our controls. These well proven original cables have set the standard
F6A/F6B/F8C/FT8D 6DR-48501-00-00 20C/D/V/30A/G/25D YMM-21207-00-00 with advanced technology that reduces friction and delivers excellent performance. The standard-core wires increase strength and reduce binding,
9.9D/15D YMM-21205-00-00 20D/25N (‘90--) 6L2-48501-11-00 allowing for a 4-inch bend radius.
9.9F/15F YMM-21206-00-00 30D (--’93) 6J8-48501-02-EJ
F15C/F20B 6AH-48501-00-00 25J/30D (‘94--) 6J8-48501-03-4D MID-RANGE CABLE (C8)
F8A/B/F9.9A/B/FT9.9A 6G8-48501-03-00
F9.9C/FT9.9D/F15A 66M-48501-00-00 This mid-range cable offers great efficiency, thanks to high level of flexibility for a reduced cable bend radius. Featuring stainless steel cables and fittings
as well as a very high resistance blue outer jacket for protection against abrasion, UV and chemicals.
F9.9F/F9.9J 6DR-48501-00-00 40Q 6R6-48501-00-00
FT9.9G/FT9.9L 6DR-48501-00-00 40X 66T-48501-01-00
PREMIUM POWERMATCHED CONTROL CABLE (YPM)
These are top-of-the-line cables, with features and performance that have made them the first choice of professional riggers. The ultra-low-friction inner
CONNECTORS FOR ATTACHMENT KITS core wire has splines and a special cover to reduce contact with the liner, allowing rigging to even tighter tolerances; another benefit is reduced ‘play’ at
Connector to motor YMM-21220-00-00 the cable ends. We strongly recommend the use of Premium PowerMatched cables for boats with severe applications and long cable lengths, on twin-
Gas connector for YMM-21205-00 YMM-21230-00-00 engine installations - and in fact, on any boat where unrivalled smoothness is is required. These cables are designed to run smoothly even if installation
Gas connector for YMM-21201-00, YMM-21202-00, YMM-21204-00, YMM-21206-00 and YMM-21207-00 YMM-21232-00-00 demands that curves or a radius be applied within the cable run.
Shift connector for YMM-21205-00 YMM-21231-00-00
Shift connector for YMM-21201-00, YMM-21202-00, YMM-21204-00, YMM-21206-00 and YMM-21207-00 YMM-21233-00-00
FEET CM STANDARD (Y32) PRICE MID-RANGE (C8) PRICE PREMIUM (YPM) PRICE
5’ 152 YMM-21005-00-00 - -
6’ 183 YMM-21006-00-00 YMM-21006-C8-00 YMM-21006-PM-30
ULTRAFLEX AND TELEFLEX CONTROLS 7’ 213 YMM-21007-00-00 YMM-21007-C8-00 YMM-21007-PM-30
Model Description Part Number Price 8’ 244 YMM-21008-00-00 YMM-21008-C8-00 YMM-21008-PM-30
Ultraflex B183 Flush Side Mount YMM-21110-00-00 9’ 274 YMM-21009-00-00 YMM-21009-C8-00 YMM-21009-PM-30
Ultraflex B85 Flush Side Mount YMM-21111-00-00 10’ 305 YMM-21010-00-00 YMM-21010-C8-00 YMM-21010-PM-30
Ultraflex B89 Side Mount White (6C-50H) YMM-21100-00-00 11’ 335 YMM-21011-00-00 YMM-21011-C8-00 YMM-21011-PM-30
Ultraflex B90 Side Mount Black (6C-50H) YMM-21100-10-00 12’ 366 YMM-21012-00-00 YMM-21012-C8-00 YMM-21012-PM-30
Teleflex Side Mount (6C-50H) YMD-RCBOX-00-10 13’ 396 YMM-21013-00-00 YMM-21013-C8-00 YMM-21013-PM-30
14’ 427 YMM-21014-00-00 YMM-21014-C8-00 YMM-21014-PM-30
15’ 457 YMM-21015-00-00 YMM-21015-C8-00 YMM-21015-PM-30
16’ 488 YMM-21016-00-00 YMM-21016-C8-00 YMM-21016-PM-30
17’ 518 YMM-21017-00-00 YMM-21017-C8-00 YMM-21017-PM-30
18’ 549 YMM-21018-00-00 YMM-21018-C8-00 YMM-21018-PM-30
19’ 579 YMM-21019-00-00 YMM-21019-C8-00 YMM-21019-PM-30
20’ 610 YMM-21020-00-00 YMM-21020-C8-00 YMM-21020-PM-30
21’ 640 YMM-21021-00-00 YMM-21021-C8-00 YMM-21021-PM-30
22’ 671 YMM-21022-00-00 YMM-21022-C8-00 YMM-21022-PM-30
23’ 701 YMM-21023-00-00 YMM-21023-C8-00 YMM-21023-PM-30
24’ 732 YMM-21024-00-00 YMM-21024-C8-00 YMM-21024-PM-30
25’ 762 YMM-21025-00-00 YMM-21025-C8-00 YMM-21025-PM-30
26’ 792 YMM-21026-00-00 YMM-21026-C8-00 YMM-21026-PM-30
27’ 823 YMM-21027-00-00 YMM-21027-C8-00 YMM-21027-PM-30
Ultraflex B183 Ultraflex B85 Ultraflex B89 Ultraflex B90 Teleflex Side Mount 28’ 853 - YMM-21028-C8-00 YMM-21028-PM-30
29’ 884 - YMM-21029-C8-00 YMM-21029-PM-30
30’ 914 YMM-21030-00-00 YMM-21030-C8-00 YMM-21030-PM-30
Yamaha recommends YPM cables. If not applicable for rigging certain types of boats, C8 or Y32 cables may be used.
