Page 214 - ULTRAFLEX Katalog 2021

THROTTLE CONVERTER

The Throttle Converter allows to steer a tension controlled
engine with a mechanical control box.

The system converts the mechanical input from a control cable Electrical
into an electrical output to the engine. 1 m mechanical cable
cable
Suitable either for new installations and refitting, it allows Voltage
controlled
to use an existing mechanical control and connect it engine
to the electrical input of the new engine’s throttle.
212 Throttle Converters can be easily packed together for multiple Throttle Converter

engines.

• Equipped with 1 m (3.28 ft) mechanical cable with C2, C8
universal end fitting
• 76 mm (3”) minimum stroke, 80 mm (3.15”) maximum stroke.
• 30 cm (1 ft) electrical wire length

Throttle Converter is suitable for most of the voltage controlled MECHANICAL
engines. For further information, please contact our Technical SHIFT
Assistance Service

Mechanical side IP65
Sensor IP67 Packed together Throttle Converters
for dual engine installations

SELECTOR UNIT FOR DUAL STATION APPLICATIONS
ACCESSORIES FOR ENGINE CONTROL CABLES

Selector unit for use with single lever controls in dual station
applications. It enables indipendent control over throttle and shift
from either the main station or the flying bridge station.

NOTE: before changing station, throttle must be on idling position
and shift in neutral.
L23 - 31649 B - only for inboard and sterndrive engines
L23

YAMAHA ENGINE KITS 2T*

K8 - 30321 A for 25 hp engines
K14F - 38098 C for 10/15 hp engines
S-2674 - 32654 X Yamaha Throttle
Connector
S-2675 - 32655 Y Yamaha Shift Connector

* Minimun order quantity:
10 pieces for part number

K8 K14F S-2674 S-2675
