Page 51 - Yamaha Zubehör Aussenbordmotoren 2017

Outboard Rigging & Accessories

ENGINE FLUSH KIT
This extremely useful piece of equipment connects in seconds to your garden hose and allows you to
flush out harmful salt and sand. It can also be used for out-of-water operation for tune-ups.

For F4/F5/F6 engines ABB-FLUSH-JD-00
For F8 to F200 engines ABB-MOTOR-FL-SH

BATTERY ISOLATOR LEADS

Allows the starter battery to be charged first, LIGHTING COIL KIT FOR F4B/F5A/ RIGGING HOSE
when other battery is being used for onboard Keep your cables protected and uncluttered with a Rigging Hose. Yamaha Hoses are tough yet
accessories. F6C flexible and are constructed from crush-resistant, UV-protected material to ensure a longer life span.
Description Part No Price ENGINE BATTERY CABLE Allows electrical power to be drawn from the Hoses are mounted using a chromium-plated copper or plastic bracket and come in black, gray or
F150A 68F-81949-02-00 engine metallic blue colours.
F175 to F350 69J-81949-02-00 Used to connect Yamaha Outboard Motors to 6BX-W8130-A0-00 Black 25ft/7,62m MAR-RIGHS-BK-25
(except V6 4.2L) 12V batteries.
F225F/F250D/ Description Part No Price Gray 25ft/7,62m ABB-RIGHS-GY-25
F300B V6 4.2L 6CE-81949-00-00 F(T)50 - F(T)60 6C5-82105-01-00 Metallic blue 25ft/7,62m ABB-RIGHS-BE-25
F70 6C5-82105-U1-00
F80/F100/F115/ 68V-82105-J1-00
F130A
F150 63P-82105-01-00 RIGGING GROMMETS
F175/F200F/F200G 6DA-82105-01-00 These handy devices replace rubber engine grommets on bigger engines and provide positive
V6 3.3L 6P2-82105-02-00 attachment without the need for clamps. They can be threaded directly onto one end of a rigging
V6 4.2L 6CB-82105-01-00 FUSE CARTRIDGES hose with Transom Brackets at the other end.
F350A 6AW-82105-01-00 115-250 (2-stroke) MAR-GROMM-ET-01
WAVERUNNER BATTERY Amps Part No Price F150 MAR-GRMMT-F1-50
Dry charge WaveRunner battery. 50 63P-82151-00-00 F200B/C-F250A/B MAR-GRMMT-LG-4S
60 6P2-82151-00-00
Description Part No Price 80 61A-82151-00-00
Battery YUASA 100 6CE-82151-00-00
YB16CLB (19AH) EU0821100900
TRANSOM PLATES
BS BATTERY Yamaha recommend these transom plates for boats with engines from 60hp and up.

New sealed and factory activated battery line by BS.
- No acid handling V4/V6 engines aluminium 10mm YMM-09TP0-00-01
- Ready & easy to use V8 engines aluminium 10mm YMM-09TP0-00-02
- Multi-positional fitment
Description Part No Max Size (mm) Price
12V-19Ah-260A 907983BB16CL 175x100x175
12V-18A -260A 907983BTX20L 1475x87x155
TRANSOM BRACKETS
The tough plastic bracket is easy to install by just threading the Rigging Hose onto it. It requires no
YAMAHA BATTERY BOXES clamp, yet provides positive engagement. Use with the rigging Grommet on the other end for quick,
easy rigging. When the chromium plated copper ''through transom bracket'' is used, the rigging hose
Size Max Battery Size Part Number Price
Small Length 277mm x Width 186mm YMM-BTBX0-00-24 is fitted with the clamp.
Large Length 327mm x Width 186mm YMM-BTBX0-00-27 Chrome transom bracket with 2 anodised stainless steel clamps ABA-THRUT-RA-SM
Plastic transom bracket MAR-THRUT-RS-M2
BATTERY CHARGERS 1

Unique battery charging technology: Fully automatic switch mode charger that analyses the state
of the battery, charges and automatically switches to maintenance charging when ready. Includes
battery testing, fault detection and float maintenance. Always ensuring a full charge to prolong TRANSOM BOLTS
battery life time. No Boat
Designed for safety: Spark-free, protected from reverse polarity connections and short-circuit proof. Total Thread Thread transom
Light and compact: Easy to store and handle. Outboard Part Number Thread length length length thickness (*) Price
Yamaha Approved: Tested and approved by Yamaha service engineers to fit and work perfectly with 90101-12M51-00 M12 95mm 60mm 35mm
the Yamaha Outboards range. 90101-12M65-00 M12 105mm 50mm 55mm
Quick connection: Combine it with YEC quick connectors - the Built-in Panel Plug, Charger Indicator 2 F25D - F300B 90101-12M03-00 M12 115mm 60mm 55mm 55-65mm
and Indicator Panel 150 - for reading the charge condition of your battery and/or for easier access 90101-12M05-00 M12 130mm 75mm 55mm 65-75mm
between your Yamaha's battery and the YEC-9 or YEC-50 charger.
901-01120-47-00 M12 150mm 75mm 75mm 75-95mm
90101-12031-
F350A M12 150mm 75mm 75mm 75-95mm
Battery Charger Part Number Price 00(**)
1 - YEC-9: 6-step charger that can charge the battery of your Yamaha YME-YEC09-EU-00 90101-12036- M12 170mm 75mm 95mm 95-115mm
outboard 00(**)
2 - YEC-50: 8-step charger that can charge the battery of your Yamaha YME-YEC50-EU-00 * Reference data
outboard. ** High tension bolts for F350A
48 49
