FITTINGS

61BCA - 71004 K TF38 - 39502 V
3/8” (9,5 mm) nut and sleeve assembly, brass 3/8” (9,5 mm) union T for tube
61CA - 71013 L VF38 - 39503 X
3/8” (9,5 mm) nut and sleeve assembly, nickel plated 3/8” (9,5 mm) bleed T for cylinder, brass
AF45-130 - 43412 T VFN38 - 39925 A
45° adjustable fitting for UC130-SVS cylinder 3/8” (9,5 mm) bleed T for cylinder, nickel plated

AF45 - 41284 A VFNO38 - 40868 Y
45° adjustable fitting, helm and tube. Suitable for 3/8” (9,5 mm) adjustable bleed T for cylinder, nickel plated, for
SilverSteer™ system only. all cylinders except UC81-OBF and UC94-OBF with serial number 99
prior to 30 1156 000001
AF90 - 74144 U
90° adjustable fitting, nickel plated brass, for standard QCFN - 41307 K
pumps (except UP18), UP20 - 42955 D and SilverSteer™ Quick connect bleed T for cylinder, nickel plated, for all
pumps. cylinders except UC94-OBF with serial number
prior to 30 1156 000001
SF38 - 39471 L
3/8” (9,5 mm) connector fitting, helm and tube QCFN94 - 41308 M
Quick connect bleed T for cylinder, nickel plated with DN5
SF12 - 41306 H quick connect, for UC94-OBF cylinders with serial number
straight fitting, helm and tube Ø 12 mm prior to 30 1156 000001
EF38 - 39472 N SF916 - 43155 Z
3/8” (9,5 mm) 90° fitting for UP18 and for helms part 9/16” (14.3 mm) nickel plated brass straight fitting
number:
37939 U - UP20 F 40153 D - UP20 T EXT-F916 - 43156 B
39618 R - UP25 F 41273 V - UP25NV F 9/16” (14.3 mm) nickel plated brass male adapter to 9/16” (14.3
39443 F - UP28 F 39422 X - UP33 F mm) female
41275 Z - UP33NV F 39415 A - UP39 F
41276 B - UP45 F 40803 T - UP25 T SF916-14 - 43301 H
39445 K - UP28 T 39446 M - UP33 T 9/16” (14.3 mm) straight fitting to 1/4 NPT
39447 P - UP39 T 41227 D - UP45 T
39970 F - UP28 R 39969 X - UP33 R
39444 H - UP39 R 41278 F - UP45 R

61BCA 61CA AF45-130 AF45

AF90 SF38 SF12 EF38

TF38 VF38 - VFN38 VFNO38 QCFN
FITTINGS

QCFN94 SF916 EXT-F916 SF916-14
