3 BOLZEN/SCHÄKEL

SPLINT DIN94 SCHÄKEL FORM D

Edelstahl AISI 316 / A4. Flaches Modell, profilierter Bügel und
Patentbolzen, Edelstahl AISI 304 / A2.

Art.-Nr. Ø x L mm Inhalt je Blister Blister je VE
40.540.001 2,0 x 20 12 6
40.540.002 2,0 x 25 12 6 Art.-Nr. C mm B mm L2 mm BL daN VE
40.540.003 2,0 x 32 12 6 08.531.040 4 10 15 600 10
40.540.004 2,0 x 40 10 6 08.531.050 5 12 17 1000 10
40.540.010 2,5 x 25 10 6 08.531.051 5 16 24 1100 10
40.540.016 3,2 x 25 8 6 08.531.052 5 16 36 1300 10
40.540.017 3,2 x 32 6 6 08.531.060 6 16 23 1400 10
40.540.018 3,2 x 40 6 6 08.531.061 6 14 40 1400 10
40.540.025 4,0 x 20 4 6
40.540.026 4,0 x 25 4 6 SCHLÜSSELSCHÄKEL
40.540.027 4,0 x 32 4 6
40.540.028 4,0 x 40 3 6
Mit profiliertem Bügel, Edelstahl
40.540.029 4,0 x 50 3 6
AISI 304 / A2.
40.540.035 5,0 x 25 2 6
40.540.036 5,0 x 32 2 6
40.540.037 5,0 x 40 2 6
40.540.038 5,0 x 50 2 6
Art.-Nr. Ø x L mm Verpackt per
Art.-Nr. C mm B mm L2 mm BL daN VE
87.540.001 2,0 x 20 100
08.536.050 5 13 25 1000 10
87.540.002 2,0 x 25 100
08.536.051 5 15 36 1000 10
87.540.003 2,0 x 32 100
08.536.061 6 20 38 1400 10
87.540.004 2,0 x 40 100
08.536.080 8 20 41 1800 10
87.540.010 2,5 x 25 100
87.540.016 3,2 x 25 100
87.540.017 3,2 x 32 100 SCHLÜSSELSCHÄKEL MIT STEG
87.540.018 3,2 x 40 100
87.540.025 4,0 x 20 100
Edelstahl AISI 316 / A4.
87.540.026 4,0 x 25 100
87.540.027 4,0 x 32 100
87.540.028 4,0 x 40 100
87.540.029 4,0 x 50 100
87.540.035 5,0 x 25 100
87.540.036 5,0 x 32 100
87.540.037 5,0 x 40 100
Art.-Nr. L mm D mm E mm W mm W1 mm BL daN
87.540.038 5,0 x 50 100
08.535.105 50 4,2 4,2 22 13 1320
08.535.106 60 6,0 6,0 25 16 1780
SCHÄKEL GEDREHT LANG - 08.535.108 80 7,0 7,0 35 22 3120
AUGBOLZEN
SCHÄKEL GEDREHT
Edelstahl AISI 316 / A4.
Geschmiedet.
Mit profiliertem Bügel, Edelstahl
AISI 304 / A2.

Art.-Nr. A mm C mm L2 mm B mm BL daN VE Art.-Nr. C mm B mm L2 mm BL daN VE
08.503.005 5 5 34 10 1600 10 08.534.050 5 12 22 1300 10
08.503.006 6 6 42 13 1950 10 08.534.051 6 14 36 1600 10
08.503.008 8 8 55 16 3000 10 08.534.080 8 18 36 1800 10
