Fuel and Energy systems

RECTIFIER/REGULATOR (F9,9L/
FT9,9L)
Allows to have stable DC current from the
engine. Required for Electric Starter Kit
6DR-W8180-00-00 or individual battery cable
68T-81949-00-00.
Description Part No QTY
Rectifier/Regulator FUSE CARTRIDGES
Assembly 68T-81960-00-00 1 Amps Part No
Bolt 97080-06012-00 1 50 63P-82151-00-00
Clamp 90465-10098-00 2 60 6P2-82151-00-00
80 61A-82151-00-00
100 6CE-82151-00-00

ENGINE BATTERY CABLE
Used to connect Yamaha Outboard Motors to
12V batteries.
Description Part No
F(T)50 - F(T)60 6C5-82105-01-00
F70 6C5-82105-U1-00
F80/F100/F115/F130A 68V-82105-J1-00
F150 63P-82105-01-00 BATTERY ISOLATOR LEADS
WAVERUNNER BATTERY F175/F200F/F200G 6DA-82105-01-00 Allows the starter battery to be charged first,
Dry charge WaveRunner battery. V6 3.3L 6P2-82105-02-00 when other battery is being used for onboard
Description Part No V6 4.2L 6CB-82105-01-00 accessories.
Battery YUASA YB16CLB EU0821100900 F350A 6AW-82105-01-00 Description Part No
(19AH) F150A 68F-81949-02-00
Battery BS BTX20HL 907983BTX20L F175 to F350 (except V6 69J-81949-02-00
Battery BSBB16CL-B 907983BB16CL 4.2L)
F225F/F250D/F300B V6 6CE-81949-00-00
4.2L

BS BATTERY
New sealed and factory activated battery line by BS.
- No acid handling
- Ready & easy to use
- Multi-positional fitment
Description Part No Max Size (mm)
12V-19Ah-260A 907983BB16CL 175x100x175
12V-18A -260A 907983BTX20L 1475x87x155

YAMAHA BATTERY BOXES
Size Max Battery Size Part Number
Small Length 277mm x Width 186mm YMM-BTBX0-00-24
Large Length 327mm x Width 186mm YMM-BTBX0-00-27

BATTERY CHARGERS 1
Unique battery charging technology: Fully automatic switch mode charger that analyses the state
of the battery, charges and automatically switches to maintenance charging when ready. Includes
battery testing, fault detection and float maintenance. Always ensuring a full charge to prolong
battery life time.
Designed for safety: Spark-free, protected from reverse polarity connections and short-circuit proof.
Light and compact: Easy to store and handle.
Yamaha Approved: Tested and approved by Yamaha service engineers to fit and work perfectly with
the Yamaha Outboards range.
Quick connection: Combine it with YEC quick connectors - the Built-in Panel Plug, Charger Indicator
and Indicator Panel 150 - for reading the charge condition of your battery and/or for easier access 2
between your Yamaha's battery and the YEC-9 or YEC-50 charger.

Battery Charger Part Number
1 - YEC-9: 6-step charger that can charge the battery of your Yamaha outboard. YME-YEC09-EU-00
2 - YEC-50: 8-step charger that can charge the battery of your Yamaha outboard. YME-YEC50-EU-00
