Page 46 - Yamaha Marine Marine Zubehör 2019

Outboard Rigging & Accessories

STEERING HOOKS

Model Type Part Number Price
6C/D/8C/9.9D/15D/40Q Ball post type, not for F8B/F9.9A/B/25J 676-48511-02-00
F6A/F8C/FT8D/F9.9C/FT9.9D/F9.9F/FT9.9G/F9.9J/FT9.9LF15A/9.9F/15F Steering guide type 63V-48511-01-00
F8A/B/F9.9A/B/25J/30D (‘87-’96) Ball post type 6G8-48511-10-00
F8A/B/F9.9A/B/25J/30D (‘87-’96) Steering guide type 6G8-48511-20-00
F15C/F20B 6AH-48511-01-00
20C(‘85-’96) 20D/25B/25D/N/30A/G (‘85-’89) Ball post type/Steering guide type 689-48511-02-00
20D/25N (‘90-’00) Ball post type/Steering guide type 6L2-48511-00-00
20D/25N (‘01-) 25J/30D (‘94--) 6J8-48511-01-4D
25J/30DETO (‘99-’01) Steering guide type 6J8-48511-52-00
F20A/F25A/F25D/F25G/FT25B/FT25F/F30A/F30B/F40B/F40F/F50F/F50H/ Steering guide type 65W-48511-01-00
FT50B/FT50G/FT50J/F60A/F60C/F60F/FT60B/FT60D/FT60G/F70A/40X
25B/50G/60F/70B Steering guide type 6H3-48511-52-00
25B/Q/40H/50D/50G/60F/70B/75A/80A/85A/90A/55B (‘95--) Ball post type 688-48511-01-4D
55B (‘92-’94) Steering guide type 688-48511-51-1D
55B (‘95-’98) Steering guide type 688-48511-52-00
55B (‘90-’94) 75A/85A (‘90-’93) Ball post type 688-48511-01-4D
75C/90A Steering guide type 688-48511-12-00
25Q/40H/50D Steering guide type 6H4-48511-51-4D
40V/Y/F40A/F45A/50H/F50A/B/FT50B/C 63D-48511-01-00
F80A/F80B/F100A/F100D Steering guide type 67F-48511-01-00
F115A Steering guide type 68V-48511-01-00

Filters and Fuel Accessories

FUEL FILTERS

Keeping your fuel clean really is an important issue where boating is concerned. Contaminated fuel affects performance and can
increase the wear and tear on your engine. The trouble is that countless small dirt particles are already in the fuel before it gets
anywhere near your boat - and that’s where Yamaha Water Separating Fuel Filters come in. They are designed to be the most efficient
systems available for removing dirt before it can enter the pumps and injection system. Without one of these, dirty, unfiltered fuel
could block the internal fuel passages, causing the engine to run poorly - or even to fail.

Instead of the standard 35/27-micron filter, the Yamaha 10-micron filter will protect your engine by removing dirt, water and small
foreign particles. These superior 10-micron filters are strongly recommended for all engines, especially HPDI and EFI models.

However, it’s important to choose a fuel filter with the right capacity for your engine and to regularly maintain it, to avoid reduced
performance and engine damage. A simple rule of thumb is to ensure that the litres-per-hour (LPH) of the filter is greater than that of
the engine. This figure can be found in your owner’s manual.

Remember, a filter that is too big or too good cannot cause problems, but one that is too small or dirty can restrict fuel flow, possibly
resulting in engine failure.

44 – Marine accessories
