Rigging Order Guide

       Y-COP


       Y-COP WITH 6X4 MULTI-FUNCTION TILLER HANDLE


        SINGLE         6X4
          ENGINE     TILLER HANDLE
























                                                                              To Engine





                                                                              To Engine














       Part Number        Description                                               Qty  Note
       Y-COP
       6X9-762D0-00-00    Y-COP Kit                                                  1
       6Y8-762A0-01-00    Y-COP Attachment Kit (required for Y-COP + 6X4 handle installation)  1
       Y-COP ATTACHMENT KIT 6X4 CONTENTS
       6X9-86261-00-00    Pigtail Bus Wire                                           1   3.6m (12 ft)
       6Y8-81920-11-00    Single hub                                                 1
       6Y8-82553-01-00    Main Bus Wire                                              1   0.3m (1 ft)
       6Y5-83553-M1-00    Wire lead                                                  1   2.5m (8 ft)
       6Y8-82117-00-00    Pigtail Bus Wire with power lead                           1

       ENGINE GROMMET FOR Y-COP HARNESS*
       6C5-42725-50-00    F50H/FT50J/F50F/FT60G                                      1
       68V-42725-20-00    F80B/F100D/F115A
       *Required for Y-COP + 6X4 Tiller Handle installations on the specific engine models listed above.
