Outboard Rigging & Accessories

STATION SELECTOR TRIM ASSIST
The touch of a button selects 2nd Press this button and Helm Master
station operation. automatically adjusts the engine
trim to your preferred setting as you
accelerate or decelerate.

SPEED CONTROL FREE THROTTLE
Once the desired rpm is reached, Allows the selected engine to be
hold it by pressing the Speed Control throttled up when the shift function
- then throttle up or down with the is disengaged.
touch of a button.

SINGLE LEVER CONTROL CENTRE ENGINE
This button synchronises the control Press the Center Engine button to
Fully Integrated Boat Control System of up to three outboards with a run only that engine when trolling -
single lever. or in no-wake zones. (Triple engine
Handling a boat with more than one outboard* has never been as easy as it is now. installations only)
Because with Helm Master’s intuitive joystick, single lever engine control, fully automatic
trim system and touch-button speed control, confident boat handling just became your
speciality! It really is that simple, because with this fully integrated drive-by-wire system,
relaxed and intuitive boat handling comes naturally - even manoeuvering and docking
become a real pleasure to look forward to. TWIN AND TRIPLE SWITCH PANELS
Just one panel controls up to three outboards.
* Helm Master is compatible with twin and triple installations of Yamaha 4-stroke V8 Engage all engines with a single key fob and
(F350A) and 4.2L V6 engines. use the 'All Start' button (triple switch panel
version only) to start them simultaneously.
KEYLESS START
The swipe of a single, keyless fob engages
multiple engines - the ultimate in streamlined
convenience. Each Helm Master™ system
allows for up to four RFID key fobs

360° DIRECTIONAL MOTION AND REAL-TIME RESPONSE
With the central pivot point near the operator and the helm, movement emanates
from this location in 360° concentric rings. Place pressure on the joystick in a given
direction and the engines respond instantly. A light push or twist of the joystick delivers
a slower-paced movement with minimal thrust, while more pressure increases thrust and
NOT JUST A JOYSTICK! movement.
Helm Master integrates all these key functions:
• Steering • Throttle • Shifting • Trim • Ignition • Engine & boat data • Security

... AND THERE’S MORE
• Easy-to-read HD 5” LCD display • Keyless electronic ignition • Anti-theft system (RFID
keyfob) • Speed-sensitive steering friction MOVING LATERALLY
Push the joystick to the left or right and your boat will respond
effortlessly. This is especially helpful when docking in tight spaces.
More force on the joystick will deliver more thrust and directional
movement. High and Standard thrust modes allow you to adjust the
thrust level quickly - to suit the conditions.
Some restrictions apply. Available on selected twin and triple Yamaha outboard
installations and only on new boat packages manufactured by participating boat
builders and sold by Authorised Dealers.
