P. 96
3 DRAHTSEIL/KAUSCHEN
DRAHTSEIL 1X19 DRAHTSEIL 1X19 PVC-MANTEL
Nicht flexibles Drahtseil für • Edelstahl A4 - AISI 316
Wantendrahtseil und Ab- • PVC-Ummantelung, weiß
spannungen. • Spule 250m
• Edelstahl A4 - AISI 316
• Spule 250m
Art.-Nr. Ø mm Bruchlast daN kg/100m Art.-Nr. Kern mm Ø mm Bruchlast daN kg/100m
02.205.202 2,0 330 2,000 02.205.505 3,0 5,0 741 4,500
02.205.225 2,5 550 3,100 02.205.506 4,0 6,0 1319 8,040
02.205.203 3,0 741 4,500
02.205.204 4,0 1319 8,040
02.205.205 5,0 2060 12,580
02.205.206 6,0 2967 18,040
02.205.207 7,0 4038 24,760
02.205.208 8,0 5275 31,800
DRAHTSEIL 7X7 RELINGDRAHT 7X7 PVC-MANTEL
Weiches Drahtseil z.B. für
Steuerseile. • Edelstahl A4 - AISI 316
• Edelstahl A4 - AISI 316 • PVC-Ummantelung, weiß
• Spule 250m • Speziell für Relingdurchzüge
und Lieken
• Spule 250m
Art.-Nr. Ø mm Bruchlast daN kg/100m Art.-Nr. Kern mm Ø mm Bruchlast daN kg/100m
02.203.202 2,0 230 1,600 02.206.206 4 6 900 6,620
02.203.203 3,0 500 3,500 02.206.207 5 7 1437 10,480
02.203.204 4,0 1000 6,300 02.206.209 6 9 2027 15,150
02.203.205 5,0 1500 9,800
02.203.206 6,0 2100 14,000
DRAHTSEIL 7X19 KAUSCHE EDELSTAHL
• Edelstahl AISI 304 / A2
Sehr flexibles Spezialdrahtseil.
• Edelstahl A4 - AISI 316
• Spule 250m
Art.-Nr. Ø mm Bruchlast daN kg/100m Art.-Nr. Draht Ø A B C D E VE
02.204.202 2,0 208 1,780 mm mm mm mm mm mm
02.204.225 2,5 400 2,400 04.107.002 2,0 7,0 14,0 17,0 4,0 2,2 25
02.204.203 3,0 469 3,950 04.107.003 3,0 10,0 17,0 22,5 5,0 3,3 25
02.204.204 4,0 834 7,060 04.107.004 4,0 11,0 18,0 25,0 6,0 4,3 25
02.204.205 5,0 1302 10,360 04.107.005 5,0 13,0 25,0 33,0 7,5 5,5 25
02.204.206 6,0 1875 15,040 04.107.006 6,0 15,0 27,0 36,0 8,5 6,5 25
02.204.208 8,0 3333 26,220 04.107.007 7,0 16,5 31,0 42,0 9,5 7,5 25
04.107.008 8,0 18,0 34,0 45,0 11,0 8,5 25
04.107.010 10,0 23,0 42,0 57,0 13,0 11,0 10
04.107.012 12,0 27,0 45,0 68,0 17,0 13,0 1
04.107.014 14,0 34,0 58,0 75,0 20,0 15,0 1
04.107.016 16,0 38,0 61,0 79,0 23,0 17,0 1
04.107.018 18,0 40,0 64,0 90,0 25,0 19,0 1
04.107.020 20,0 45,0 77,0 102,0 29,0 21,0 1
94 RIGG www.lankhorst-hohorst.de
