ARKIP 530 BR SPORTSMAN 445 CATCH SPORTSMAN 400 with 9 foot oars INKAS 525

SPORTSMAN 355 with 8 foot oars INKAS 495

SPORTSMAN 445 MAX

ARKIP 460
FISHING 440 with 9 foot oars INKAS 465

SPORTSMAN 445 BASIC with 9 foot oars
FISHING 410 with 8½ foot oars INKAS 465L

ARKIP ARKIP SPORTSMAN SPORTSMAN SPORTSMAN SPORTSMAN SPORTSMAN FISHING FISHING
530 BR 460 445 CATCH 445 MAX 445 BASIC 400 355 440*** 410
530 cm
Length 460 cm 451 cm 451 cm 451 cm 401 cm 355 cm 431 cm 403 cm Length
(576 cm with bathing platform)
Width 214 cm 185 cm 175 cm 175 cm 175 cm 164 cm 146 cm 164 cm 156 cm Width
Weight 610 kg 292 kg 252 kg 227 kg 189 kg 125 kg 84 kg 94 kg 75 kg Weight
Max. weight with motor 829 kg 475 kg 397 kg 372 kg 319 kg 271 kg* 157 kg 139 kg 97 kg Max. weight with motor
Freeboard height 81 cm 58 cm 50 cm 50 cm 50 cm 47 cm 45 cm 50 cm 50 cm Freeboard height
Interior height 67 cm 60 cm 60 cm 60 cm 60 cm 60 cm 51 cm 54 cm 57 cm Interior height
Hull depth 112 cm 80 cm 73 cm 73 cm 73 cm 63 cm 54 cm 60 cm 63 cm Hull depth
Hull thickness 2.7 mm 2.4 mm 2.0 mm 2.0 mm 2.0 mm 1.8 mm 1.7 mm 1.7 mm 1.7 mm Hull thickness
Hull angle 16° 12° 9° 9° 9° 8° 2° – – Hull angle
6 – 10 hp (4.4 – 7.4 kW)
Rec. motor 70 – 100 hp (51 – 74 kW) 30 – 50 hp (22 – 37 kW) 20 – 30 hp (14.7 – 22 kW) 20 – 30 hp (14.7 – 22 kW) 10 – 20 hp (7.4 – 14.7 kW) 6 – 8 hp (4.4 – 5.9 kW) 2.5 – 5 hp (1.9 – 3.7 kW) 2.5 – 3.5 hp (1.9 – 2.6 kW) Rec. motor
15 – 20 hp (11 – 14.7 kW)**
Rec. Torqeedo T ex Torqeedo Cruise 10.0 R T ex Torqeedo Travel 1003 Rec. Torqeedo
electric drive (10.0 kW) (1030 W) electric drive
Max. motor power 100 hp (74 kW) 50 hp (37 kW) 30 hp (22 kW) 30 hp (22 kW) 20 hp (14.7 kW) 20 hp (14.7 kW) 8 hp (5,9 kW) 5 hp (3.7 kW) 3.9 hp (2.9 kW) Max. motor power
Side console 1.80 m
Control cable length 4.80 m 2.10 m 2.10 m 1.80 m Control cable length
Mid console 2.70 m
Side console 2.40 m
Steering cable length 4.80 m 2.70 m 2.70 m 2.40 m Steering cable length INKAS INKAS INKAS INKAS
Mid console 3.30 m 525 495 465 465L
Shaft length Long Long Long Long Long Long Short Short Short Shaft length
Max. load 675 kg 525 kg 465 kg 465 kg 484 kg 420 kg 320 kg 400 kg 300 kg Max. load Lengt 525 cm 495 cm 465 cm 465 cm
90 cm
85 cm
85 cm
90 cm
Width
Max. no. people 6 5 3 4 4 4 3 4 3 Max. no. people Weight
Approved bow eye Insurance class 3 Insurance class 3 Insurance class 3 Insurance class 3 Insurance class 3 Insurance class 3 Insurance class 3 Insurance class 3 Insurance class 3 Approved bow eye 38 kg 36 kg 33 kg 28 kg
Bow/stern height 35 cm 33 cm 33 cm 33 cm
Ce marked for Ce marked for
category C – Inshore C – Inshore C – Inshore C – Inshore C – Inshore D – Sheltered waters D – Sheltered waters D – Sheltered waters D – Sheltered waters category Load capacity 400 kg 400 kg 340 kg 340 kg
2 persons, 100-hp motor 2 persons, 50-hp motor 2 persons, 30-hp motor 1 person, 30-hp motor 1 person, 20-hp motor 1 person, 20-hp motor 1 person, 8-hp motor 1 person, 5-hp motor 1 person, 2-hp motor Max. no. people 3 2 2 2
Max. speed Max. speed
gives approx. 38 knots gives approx. 32 knots gives approx. 25 knots gives approx. 26 knots gives approx. 24 knots gives approx. 25 knots gives approx. 19 knots gives approx. 11 knots gives approx. 8 knots Hull thickness 1.25 mm 1.25 mm 1.25 mm 1 mm
2 * Incl. steering console and 20-hp motor. ** With steering console. *** Fishing 440 has the market’s lowest petrol consumption – 0.11 litres per sea mile with 1 person at 7 knots. 3
