Page 184 - Lankhorst Katalog 2021/2022
P. 184
4 LEWMAR BLÖCKE
HTX BLOCK 1-SCHEIBIG
Art.-Nr. Fabr.-Nr. Scheiben-Ø mm Max. Schot mm SWL daN BL daN
67.569.501 29195001 50 10 800 1600
67.569.601 29196001 60 12 1100 2200
67.569.701 29197201 72 14 2000 4000
67.569.901 29199001 90 16 3500 7000
HTX BLOCK 2-SCHEIBIG
Art.-Nr. Fabr.-Nr. Scheiben-Ø mm Max. Schot mm SWL daN BL daN
67.569.502 29195002 50 10 800 1600
67.569.602 29196002 60 12 1100 2200
67.569.702 29197202 72 14 2000 4000
HTX BLOCK 3-SCHEIBIG
Art.-Nr. Fabr.-Nr. Scheiben-Ø mm Max. Schot mm SWL daN BL daN
67.569.503 29195003 50 10 800 1600
67.569.603 29196003 60 12 1100 2200
HTX BLOCK 1-SCHEIBIG MIT HF
Art.-Nr. Fabr.-Nr. Scheiben-Ø mm Max. Schot mm SWL daN BL daN
67.569.504 29195004 50 10 800 1600
67.569.604 29196004 60 12 1100 2200
67.569.703 29197204 72 14 2000 4000
67.569.904 29199004 90 16 3500 7000
HTX BLOCK 2-SCHEIBIG MIT HF
Art.-Nr. Fabr.-Nr. Scheiben-Ø mm Max. Schot mm SWL daN BL daN
67.569.505 29195005 50 10 800 1600
67.569.605 29196005 60 12 1100 2200
182 DECKBESCHLÄGE www.lankhorst-hohorst.de
